Pedeck Cradle 1250 Adjustable Decking Cradle 20mm Extender

The Pedeck Cradle 1250 Adjustable Decking Cradle 20mm Extender is designed to increase the height range of the compatible Pedeck/Rubbertech Adjustable Decking Cradle by 20mm per extender.

Ideal for raised decking, roof terraces, balconies, patios and raised flooring applications, the extender provides a simple modular way to increase the cradle height without changing the complete support system.

The standard Adjustable Decking Cradle provides a 12mm to 50mm adjustment range. Adding one 20mm extender increases this to approximately 32mm to 70mm, while two extenders increase the available height to approximately 52mm to 90mm.

20mm Extension for the Pedeck Adjustable Decking Cradle

Each Pedeck Cradle 1250 Extender adds 20mm to the height of the compatible Adjustable Decking Cradle.

This allows the same cradle system to accommodate greater finished floor or decking heights while retaining its adjustable design.

The extender is particularly useful for projects where different support heights are required across the same installation.

Pedeck Cradle Height Ranges

The standard Pedeck Adjustable Decking Cradle can be adjusted from approximately 12mm to 50mm.

Adding 20mm extenders progressively increases this height range:

  • No Extender: 12mm to 50mm
  • 1 x 20mm Extender: 32mm to 70mm
  • 2 x 20mm Extenders: 52mm to 90mm
  • 3 x 20mm Extenders: 72mm to 110mm

Each additional compatible extender adds a further 20mm to the cradle height.

This modular arrangement provides flexibility when configuring the support system for different finished surface levels.

Ideal for Raised Decking

The Pedeck Cradle system provides an adjustable support for compatible decking substructures.

Rather than constructing a conventional support directly from the substrate, the decking framework can be raised using individual adjustable cradles.

Where the required support height exceeds the standard cradle range, the 20mm extender provides additional height.

Typical applications include:

  • Garden decking
  • Patio decking
  • Roof terrace decking
  • Balcony decking
  • Porches
  • Landscaped areas
  • Raised floors
  • Sheds and outbuildings

Designed for Compatible 50mm Decking Joists

The Pedeck Adjustable Decking Cradle system is designed for use with a compatible decking substructure, including suitable 50mm joists.

The cradle supports the decking framework, with the finished decking subsequently installed onto the supported substructure.

The 20mm extender increases the cradle height while retaining the same basic support arrangement.

Joist dimensions, spans, support centres and fixing requirements should be appropriate for the complete decking system and anticipated loading.

Quick Height Adjustment

The wider Pedeck Adjustable Decking Cradle incorporates a quick adjuster ring, allowing the support height to be altered during installation.

This adjustment can even be carried out after sections of the decking substructure have been positioned, helping installers achieve an accurate finished level.

Adding 20mm extenders increases the available adjustment range where greater support heights are required.

Ideal for Low and Medium Height Decking

The combination of adjustable cradle and modular extenders makes the system particularly versatile for low and medium-height decking installations.

The standard cradle can accommodate very low build-ups from approximately 12mm, while extenders allow the support height to be progressively increased.

This can be useful where:

  • Door threshold heights need to be matched
  • The substrate varies in level
  • Additional clearance is required beneath decking
  • A drainage void is required
  • Different support heights are needed across the installation

Suitable for Roof Terrace Decking

The Pedeck Adjustable Decking Cradle system can be used for compatible roof terrace decking installations.

Raised decking allows the finished deck and supporting substructure to sit above the underlying surface, creating a void beneath.

Where additional height is required, the 20mm extender provides a modular method of increasing the cradle build-up.

The complete support arrangement should be compatible with the roof construction, waterproofing system and intended loads.

Suitable for Balcony Decking

The adjustable cradle system is also suitable for compatible raised balcony decking.

Balcony installations can involve restricted threshold heights or variations across the supporting surface.

The adjustable cradle allows the support height to be fine-tuned, while the 20mm extender provides additional height where the standard adjustment range is insufficient.

Suitable for Decking Over Patios

The Pedeck Cradle system provides an alternative method of supporting decking above a suitable existing patio or solid substrate.

Individual cradles can be adjusted to help create the required level for the decking substructure.

The 20mm extenders provide additional flexibility where a greater distance is required between the patio and finished decking.

Create a Void Beneath Raised Decking

Increasing the cradle height creates additional space beneath the decking substructure.

Depending on the design of the installation, this void can provide space for suitable:

  • Drainage
  • Cables
  • Pipework
  • Small building services
  • Other compatible components

The void can also provide separation between the decking substructure and supporting surface.

Any services positioned beneath the deck should be appropriately designed and should not obstruct drainage.

Raised Flooring Without a Levelling Screed

The Pedeck Adjustable Cradle can also be used for suitable raised floor applications.

Where appropriate, adjustable supports can help compensate for variations in the underlying surface without first creating a conventional levelling screed.

The 20mm extender allows the cradle height to be increased where a greater floor build-up is required.

This can potentially reduce the amount of material and preparation required compared with traditional levelling methods, depending on the particular floor construction.

Manufactured From Recycled Plastic

The Pedeck 20mm Extender features a recycled plastic body, providing a lightweight and durable component for compatible cradle installations.

Its modular construction allows additional height to be introduced without replacing the complete adjustable cradle.

Pedeck Cradle 1250 20mm Extender Benefits

  • Adds 20mm of additional height
  • Designed for the Pedeck/Rubbertech Adjustable Decking Cradle
  • Modular height extension
  • Quick to incorporate during installation
  • Allows greater finished decking heights
  • One extender increases cradle range to approximately 32-70mm
  • Two extenders increase cradle range to approximately 52-90mm
  • Additional compatible extenders provide further 20mm increments
  • Suitable for raised decking
  • Ideal for roof terraces
  • Suitable for balconies
  • Suitable for patios
  • Suitable for landscaping
  • Suitable for raised flooring applications
  • Manufactured from recycled plastic
  • Allows accurate finished surface levels
  • Suitable for residential and commercial projects

Pedeck Adjustable Decking Cradle Applications

The wider Pedeck Cradle system can be used for:

  • Landscaping
  • Garden decking
  • Raised decking
  • Decking over patios
  • Roof terrace decking
  • Balcony decking
  • Porches
  • Sheds and outbuildings
  • Indoor raised flooring
  • Other compatible raised floor applications

Pedeck Cradle 1250 20mm Extender Technical Information

  • Product: Pedeck Cradle 1250 Adjustable Decking Cradle 20mm Extender
  • Product Type: Decking Cradle Height Extension
  • Height Increase: 20mm per extender
  • Material: Recycled Plastic
  • Length: 128.4mm
  • Width: 128.4mm
  • Height: 20mm
  • Compatible Product: Pedeck/Rubbertech Adjustable Decking Cradle
  • Standard Cradle Range: 12mm to 50mm
  • With 1 Extender: 32mm to 70mm
  • With 2 Extenders: 52mm to 90mm
  • Application: Compatible decking substructures and raised flooring systems

What Is a Decking Cradle Extender?

A decking cradle extender is an accessory designed to increase the height of a compatible adjustable decking cradle.

The Pedeck Cradle 1250 Extender adds 20mm to the support arrangement, allowing greater finished decking or flooring heights to be achieved.

How Much Height Does Each Pedeck Cradle Extender Add?

Each extender adds 20mm to the height of the compatible adjustable cradle.

This means the support height can be progressively increased in 20mm increments.

What Height Does the Adjustable Decking Cradle Cover Without an Extender?

The standard Pedeck Adjustable Decking Cradle provides an adjustment range of approximately 12mm to 50mm.

This makes it suitable for relatively low-profile decking and raised flooring installations.

What Height Does the Cradle Cover With One 20mm Extender?

Adding one Pedeck 20mm Extender increases the available adjustment range from 12-50mm to approximately 32mm to 70mm.

What Height Does the Cradle Cover With Two 20mm Extenders?

Using two compatible 20mm extenders increases the available adjustment range to approximately 52mm to 90mm.

Can I Use More Than Two Extenders?

The supplied system information indicates that additional extenders can be used to progressively increase the height in 20mm increments.

For example:

  • 3 extenders: approximately 72-110mm
  • 4 extenders: approximately 92-130mm

For higher installations, the permitted configuration and stability requirements of the complete cradle system should be confirmed.

Can the Extender Be Used on Its Own?

No. The 20mm Extender is an accessory for the compatible Pedeck/Rubbertech Adjustable Decking Cradle.

It is not designed to function as a standalone decking support.

Is the Extender Adjustable?

The extender itself provides a fixed 20mm increase in height.

The height adjustment is provided by the compatible Adjustable Decking Cradle, with the extender increasing its overall available height range.

Can It Be Used for Garden Decking?

Yes. The wider adjustable cradle system is suitable for compatible garden and landscaping decking installations.

The 20mm extender is useful where additional clearance is required between the substrate and decking substructure.

Can It Be Used for Roof Terrace Decking?

Yes. The Pedeck Adjustable Decking Cradle system can be used for suitable roof terrace applications.

The complete cradle, decking substructure, waterproofing and roof construction should be checked for compatibility with the intended application and loading.

Can It Be Used for Balcony Decking?

Yes. The extender can form part of a compatible adjustable cradle system for raised balcony decking.

Its 20mm incremental height increase can be useful when working around restricted balcony thresholds.

Can the Cradle System Replace a Levelling Screed?

For suitable raised flooring applications, the adjustable cradle system can be used to compensate for variations in the supporting surface, potentially removing the need for a conventional levelling screed.

Whether this is appropriate depends on the complete floor construction, loading and project specification.

How Many Decking Cradles Do I Need?

The number of cradles required depends on the decking substructure, joist dimensions, span requirements and anticipated loading.

The supplied system performance information references a minimum of six supports per square metre for its stated load rating, but the actual support layout should be determined according to the complete decking or flooring system being installed.

Does Adding an Extender Change the Load Capacity?

The supplied technical information provides a load rating for the wider decking cradle system, but does not provide separate verified load figures for every possible extended configuration.

For this reason, the load capacity of a particular extended cradle arrangement should be confirmed where structural loading is critical, especially when using multiple extenders or creating higher support configurations.

20mm Height Extension for Pedeck Adjustable Decking Cradles

The Pedeck Cradle 1250 Adjustable Decking Cradle 20mm Extender provides a simple modular way to increase the height of compatible adjustable decking supports.

Each extender adds 20mm, increasing the standard cradle range of 12-50mm to 32-70mm with one extender or 52-90mm with two extenders.

Ideal for raised decking, roof terraces, balconies, patios, landscaping and suitable raised flooring applications, the extender provides additional flexibility when the standard cradle height is insufficient to achieve the required finished surface level.

Technical Data

Download TDS



Additional information

Weight 1.26 kg
SKU D-1296/20 Categories , , Tag Brand:
